¶ Version Introduction
Version V1.5.1 adds support for the 8×5G_Base-T output card, MVR output card, Dynamic Booster for card-based controllers, along with other enhancements and bug fixes.
| Product | Model |
|---|---|
| LED Display Controller | MX6000 Pro, MX2000 Pro, MX40 Pro, MX30, MX20, KU20, CX40 Pro |
| Input Card |
MX_4×HDMI 2.0 input card MX_2×HDMI 2.1 input card MX_4×DP 1.2 input card MX_2×DP 1.4 input card MX_4×12G-SDI input card MX_1×DP 1.4+1×HDMI 2.1 input card MX_1×ST 2110 (25G) input card MX_2×ST 2110 (25G) input card MX_1×ST 2110 (100G) input card MX_1×DP 1.4 input card (8K@60Hz) |
| Output Card |
MX_4×10G_Fiber output card MX_1×40G_Fiber output card MX_8×5G_Base-T output card (New Released) |
| MVR Card | MX_1×HDMI 2.0+1×12G-SDI MVR output card (New Relased) |
| Receiving Card | A10s Pro and its derivative cards, CA50E, XA50 Pro, A8s Pro and its derivative cards, A8s and its derivative cards, A8s-N, A7s Plus, A5s Plus, B6s |
| Fiber Converter | CVT10, CVT10 Pro, CVT8-5G |
| Multifunction Card | MFN300 |
| Brightness Sensor | NS060 |
| 3D Emitter | EMT200 Pro |
More infomation about V1.5.1 software and hardware firmware (controller and RV card) please check Release Note Page
¶ Key Features
¶ MVR
By supporting the MVR function, the shortcoming of full-link signal observation capabilities is completely addressed. It not only allows users to compare input sources and output effects in real time to quickly locate signal abnormalities or image quality differences, but also provides stronger operational and maintenance guarantees for high-standard scenarios such as broadcasting and studios through visual monitoring methods.
More info about MVR card please check MX_1×HDMI 2.0+1×12G-SDI MVR Card
- Add an independent MVR interface to monitor input sources and output effects simultaneously.
- Add a fixed layout template function, supporting one-click loading of output monitoring and input preview, as well as operations such as drag-and-drop replacement, deletion, clearing, and layout switching.
- Add a layout customization function. After window properties are defined, they can be saved as a template. When the template is applied, content will be automatically filled according to the properties.
- Add the Multiviewer interface resolution settings, supporting 1920×1080 and 3840×2160 (default).
- Add the UMD function, supporting on/off toggling and color customization. When enabled, it displays the source name or screen name.
- Add the border function, supporting on/off toggling, color customization, and thickness adjustment.
More info about VMP MVR interface please check MVR Page
¶ 8×5G_Base-T Output Card
By providing a 5G-bandwidth Ethernet output card for card-based controllers, the need for separate fiber converters is completely eliminated. It not only simplifies the system architecture for non-long-distance 5G transmission scenarios, but also reduces overall cost and deployment complexity.
More info about 8×5G_Base-T output card please check MX_8×5G_Base-T Output Card
¶ Dynamic Booster Supported by Card-based Controllers
By supporting the Dynamic Booster function for card-based controllers, ordinary low-dynamic images can be reshaped into stunning HDR-level visual effects. This technology not only accurately restores dark details and eliminates image banding caused by "low grayscale merging," but also significantly reduces overall screen energy consumption through power scheduling, providing customers with a solution that balances ultimate image quality with green energy savings.
- MX2000 Pro and MX6000 Pro support the Dynamic Booster function.
- Enable or disable Dynamic Booster at the screen level.
- Adjust the Dynamic Booster level at the screen level.
¶ Controller Discovery and Maintenance in Abnormal States
When the system detects no output card or that the output card version does not match the controller firmware version, VMP still needs to maintain communication capability with the controller, supporting controller discovery and firmware update functions to ensure the controller can be managed and compatibility issues can be fixed via software.
¶ Controller Firmware Update
Optimize the firmware update process and improve the firmware package transmission method to avoid false positive interception by some antivirus software, ensuring stable and reliable updates.
¶ EOTF Low-Grayscale Compensation Optimization
After optimization, 10-bit and 12-bit start glowing step by step at 33.3% at 100% brightness.
